WELDY MINIWELDER GEO2
NORMALLY AVAILABLE WITHIN 2 TO 4 WEEKS, WITH THE OPTION FOR URGENT AIRFREIGHT. CONTACT US NOW FOR A SPEEDY SHIPPING QUOTE.
The lightweight and quick WELDY GEO2 is an entry-level hot-wedge welder purpose-built for geomembrane welding. It is suitable for HD-PE, LD-PE, TPO, FPO and similar materials with thicknesses ranging from 0.5 to 1.5mm (HD-PE 0.4-1.0mm; TPO 0.7-1.5mm). The GEO2 distinguishes itself with revolutionary chain-free drive technology, automatic wedge positioning and genuinely intuitive operation - the operator simply turns the heating and drive on/off with two buttons and fine-tunes wedge temperature and drive speed with two rotary dials, with two LED indicators showing process status at a glance.
MAIN APPLICATIONS
- Shrimp farming and fish farming tank construction
- Water basins and water tanks
- Horticulture and gardening projects
- Foundation waterproofing
- Pond and canal lining
KEY FEATURES
- Incredibly lightweight - under 4 kg (3.9kg)
- Welding speeds up to 7.5 metres per minute
- Revolutionary drive technology, free from cumbersome chains
- Automatic wedge positioning for a streamlined workflow
- Unbeatable ease of use, even for beginners
- Stainless steel hot wedge, 50mm length x 36mm width
- Weld seam width 2 x 12mm, max overlap 100mm
- Voltage 230V, 800W, 50/60Hz
- Wedge temperature range 60-480°C, speed range 0.4-7.5m/min
- Compact dimensions 228 x 228 x 170mm
MACHINE ACCESSORIES
Browse compatible nozzles, welding shoes and consumables for this machine in our Plastic Welding Accessories collection.
GENERAL ACCESSORIES
See spare parts and general workshop consumables in our Plastic Welding Spare Parts collection.
