SENFENG TXP Series Laser & Flame Hybrid Cutting Machine 12030TXP
Hybrid laser+flame cutting that reaches 200mm plate at a fraction of pure-laser cost.
Heavy equipment manufacturing, shipyards, and power-tower producers cutting 40-200mm carbon steel.
Available in 1 standard configuration, 20kW.
- Combines a fiber laser head with oxy-fuel (flame) cutting in one machine, switchable by replacing the ceramic body
- Cuts 200mm ultra-thick plate with a 20kW system — a task that would typically need 80kW of pure laser, cutting purchase cost by around 60%
- In hybrid mode laser output drops to just 4kW, saving over 35% energy and around 40% per-unit cutting cost versus pure laser cutting
- Automatic ignition and perpendicularity compensation remove manual setup steps
- ±45° bevel cutting head (V/X/Y/K shapes) with 3D five-axis bus-based control
- Piercing time for 200mm ultra-thick plate is under 15 seconds — over 5x faster than conventional preheat/bench-drilling methods
Size & Power Comparison
| Model | Laser Power (kW) | Straight-Cut Area (mm) | Bevel-Cut Area (mm) | Max. Load (kg) | Overall Dimensions (mm) | Max. Acceleration (G) |
|---|---|---|---|---|---|---|
| 12030TXP | 20 | 12000*3000 | 11400*2000 | 28260 | 15612*4746*1950 | 0.8 |
Frequently Asked Questions
What plate thickness can the 12030TXP cut?
The 12030TXP cuts 1-200mm carbon steel, combining a 20kW fiber laser with oxy-fuel flame cutting in one machine. Always confirm your exact plate thickness and material with our team before ordering, as tooling and gas setup affect real-world capacity.
