SENFENG SF1313N Series Fiber Laser Cutter 1313N
Industrial-grade cutting in a 1300x1300mm footprint, built for startups and small-scale fabricators.
Part of SENFENG's SF1313N series — Compact Fiber Laser Sheet Cutter — SF1313N, built for Startups and small-scale fabricators needing a lower upfront investment and a small footprint.
The 1313N has a 1300*1300mm working area at 1.5-6kW.
- 1300*1300mm fully-enclosed footprint delivers industrial-grade precision without a large factory floor
- Embedded operating screen prevents collisions; panoramic visual monitoring lowers the learning curve
- Auto Edge Detection auto-calibrates plate position for high-precision cuts with minimal taper
- Intelligent smoke-free dust extraction with zoned suction activated by cutting head position
- Jump Function reduces idle travel by up to 70%, cutting cycle time and consumable use
- Fits one 20GP or 40HQ container for economical overseas shipping
| Laser Power | 1.5-6 kW |
| Working Area (L*W) | 1300*1300 mm |
| X/Y-axis Positioning Accuracy | ±0.05 mm |
| X/Y-axis Repositioning Accuracy | ±0.02 mm |
| Max. No-load Speed | 100 m/min |
| Max. Acceleration | 1 G |
| Max. Load of Platform | 300 kg |
| Overall Dimensions (L*W*H) | 2860*3720*1963 mm |
| Power Supply | Three-phase 380V, 50/60Hz (custom-made) |
Frequently Asked Questions
What can the SF1313N Series 1313N cut?
The 1313N has a 1300*1300mm working area and runs at 1.5-6kW. Always confirm your exact material, thickness, and platform load requirements with our team before ordering.
Have more questions about SENFENG metal sheet cutters? See our SENFENG Metal Sheet Cutters FAQ.
