Side-mounted-bed cutter tuned for material-efficient small-and-medium tube processing.

Part of SENFENG's S2 series — 1.5kW-6kW Tube Laser Cutter for Small and Medium Tubes — S2 Series, built for Small and medium tube processing balancing cutting precision, efficiency, and material waste.

The 9024S2 handles tube size Φ20-240mm / □20-240mm at 3-6kW with 2 chucks.

  • Side-mounted bed design feeds tube directly under the chuck for higher loading efficiency
  • High-precision chuck for stable, accurate cutting
  • Rear chuck air-blowing extends service life
  • Ultra-short tailing design (~50-80mm) minimizes material waste
  • Optional Vari-pitch or Follow-up Support reduces tube sagging
  • Automatic loading device lowers labor cost; integrated temperature-controlled cabinet
Laser Power 3-6 kW
Max. Length of Tube 9000 mm
Tube Size Φ20-240mm / □20-240mm
Max. Load of Chucks 300 kg
X/Y-axis Positioning Accuracy ±0.05 mm
X/Y-axis Repositioning Accuracy ±0.03 mm
Max. No-load Speed 120 m/min
Max. Chuck Rotating Speed 100 r/min
Max. Acceleration 0.8 G
Power Supply Three-phase/380V/50Hz
Chucks 2

Frequently Asked Questions

What can the S2 Series 9024S2 cut?
The 9024S2 handles tube sizes Φ20-240mm / □20-240mm at 3-6kW. Always confirm your exact tube dimensions, material, and weight requirements with our team before ordering.
