Modular, ultra-large-format cutting for shipbuilding, bridges, and heavy engineering — up to 50 metres long.

Shipbuilding, bridge construction, and heavy engineering machinery cutting oversized, super-heavy plate.

Available in 8 standard configurations, 6-60kW.

  • Modular spliced bed lets length and width be tailored to the job, easing transport of oversized workpieces
  • Ground-rack bed construction for stability and rigidity at high cutting speed
  • Anti-burning graphite bed plates resist heat and molten slag, extending machine life
  • Follow-up blow-suction fume control captures over 95% of fume
  • Full process-technology suite: Flash Piercing, Vision-based Nesting, Automatic Nozzle Changing, Perfect Finish Cut, Smooth/Progressive/Deslag Piercing, Smooth MicroJoint, Jump Function, Auto Edge Detection, Countersink Cutting
  • Optional UV inkjet marking, galvanometer marking, powder-spray scribing, and physical engraving for shipyard traceability

Size & Power Comparison

Model Laser Power (kW) Working Area (mm) Max. Load (kg) Overall Dimensions (mm)
SF6030R 6-60 6000*3000 14130 8360*4746*1950
SF8030R 6-60 8000*3000 18840 10680*4746*1950
SF12030R 6-60 12000*3000 28260 15612*4746*1950
SF14030R 6-60 14000*3000 32970 17830*4746*1950
SF24040R 6-60 24000*4000 75360 29861*4746*1950
SF30040R 6-60 30000*4000 47000 36956*4746*1950
SF36030R 12-60 36000*3000 84780 45500*4746*1950
SF50030R 12-60 50000*3000 117750 63100*4746*1950

Frequently Asked Questions

How is the R Series sized for my job?
The R Series ships in eight standard bed sizes from 6000×3000mm up to 50000×3000mm, each rated 6-60kW (12-60kW on the largest two). Because these are modular, shipyard-scale installations, always confirm your exact plate size, power, and platform load with our team before ordering.
