SENFENG GT Series Tube Laser Cutter SF6035GT
Precision beveling for seamless welding prep on small-to-medium tube.
Part of SENFENG's GT series — 3kW-6kW Beveling Tube Laser Cutter — GT Series (Two Chucks), built for ±45° bevel cutting on round, square, rectangular, oval tubes and profiles for weld-ready edges.
The SF6035GT handles tube size Φ20-360mm / □20*20-360*360mm at 3-6kW with 2 chucks.
- Two-chuck design supports straight cutting and ±45° bevel cutting
- High-precision dust-proof aluminium two-chuck construction
- Follow-up support system and Error Determination for stable cutting
- Profiles Centering auto-centers H/U/L beam profiles; Single-faced Centering for flat stock
- Suitable for small-to-medium tube diameters and short workpieces
- Full process-technology software suite: Nesting, Special Edge-Sharing, Fast Import, Automatic Sorting, Profiles Processing
| Laser Power | 3-6 kW |
| Max. Length of Tube | 2000-6400 mm |
| Tube Size | Φ20-360mm / □20*20-360*360mm |
| Max. Weight of Tube | 500 kg |
| X/Y-axis Positioning Accuracy | ±0.05 mm |
| X/Y-axis Repositioning Accuracy | ±0.03 mm |
| Max. No-load Speed | 60 m/min |
| Max. Chuck Rotating Speed | 60 r/min |
| Overall Dimensions (L*W*H) | 10200*2280*2530 mm |
| Power Supply | Three-phase 380V, 50Hz/60Hz (custom-made) |
| Chucks | 2 |
Frequently Asked Questions
What can the GT Series SF6035GT cut?
The SF6035GT handles tube sizes Φ20-360mm / □20*20-360*360mm at 3-6kW, up to 2000-6400mm long. Always confirm your exact tube dimensions, material, and weight requirements with our team before ordering.
Have more questions about SENFENG tube laser cutters? See our SENFENG Tube Laser Cutters FAQ.
