Heavy-duty strength meets extreme stability, engineered for maximum tonnage.

Part of HARSLE's MegaBend series — Heavy-Duty & Large-Scale Bending, built for heavy infrastructure & shipbuilding.

This 100060 configuration delivers 1000 tonnes (10000 kN) of bending force across a 6000mm bending length.

Heavy-duty welded reinforced frame for high-tonnage rigidity
Handles thick, high-strength plate with consistent accuracy
Dual AC or dual servo motor drive
Front and rear support systems for long/heavy sheets
Side-feeding or front-feeding configurations
Laser protection supplied as standard

CNC Control Options

DELEM 58Tx: 18.5-inch touchscreen with graphical programming, bending-process calculation and collision checking.
DELEM 53Tx: 15.6-inch touchscreen with integrated 2D programming for intuitive, accurate operation.

Drive System

Dual AC Motors: Deliver stable, synchronized force output for reliable performance under heavy-duty conditions.
Dual Servo Motors: Provide fast response, precise control and energy-efficient operation for high-accuracy, high-speed bending.

Reinforced Frame

A heavy-duty welded structure delivers exceptional rigidity and stability for high-tonnage, high-load bending, handling thick and high-strength materials with consistent accuracy.

Safety and Tooling

Front Support: Supports large sheets from the front, reducing sagging and misalignment during bending.
Back Support: Additional rear support for long, heavy sheets, improving balance and preventing material sagging.

Automation & Handling

Side or Front Feeding: Side feeding suits oversized or irregular workpieces; front feeding suits standardized mass production with automated, consistent positioning.

Precision Tooling

Punches & Dies: gooseneck, acute, radius, hemming and multi-V profiles, hardened to 58-62 HRC. Quick-Clamp Systems: tool changes in under 3 minutes, WILA/Amada/Euro compatible. ±0.01mm CNC precision-ground for repeatable bending angles.

Key Specifications

Bending Force	10000 kN
Bending Length	6000 mm
Column Distance
