Diamond Edge Polishing Machines
BERMAQ - Diamond Edge Polishing Machine AMT for Acrylic and Methacrylate (PMMA)
Freight quoted separately
Request a written quotation to confirm the selected configuration, availability and delivery cost.
Request a quote including freightProduct information
The edge polishing machine AMT is a table-top tilting machine perfect for processing small workpieces. Thanks to its tilting capability, it is able to polish the edges of the acrylic and methacrylate (PMMA) pieces in bevels up to 60°.
If you are looking for a practical, handy, easy to use, versatile and, above all, with a high-quality finish, the AMT edge polisher is your machine. Recommended for displays, decorative elements and stand elements.
Technical specifications
- Working length: 700 mm
- Automatic feeding
- Workpiece hold-down system: clamp
- Maximum thickness:
- 35 mm: straight angles
- 20 mm: at 45º tilt angle
- Regulable cutting depth: 0 – 1,5 mm
- Motor speed: from 7000 rpm to 12000 rpm
- Feed speed: from 0 to 1,50 m/min
- Minimum / maximum inclination: from –3º to +60º
- Milling angles: 15º 22,5º 30º 45º and 60º
- Power supply: 220 V 1PH / 50/60 Hz
- Outer machine dimensions: 792 x 539 x 267 mm
Applications
- Methacrylate display stand polishing
- Methacrylate decoration elements
- Stand elements
- Gifts and jewellery
- AMT Suction system: 230V /1200W
Watch the AMT in action
https://youtu.be/WzMQq_9m0Ps
Request a quote including freight
Tell us your requirements and delivery address so we can prepare a quotation including freight.
